HKW 3 CORE NEOPRENE CABLE (H07RN-F 450/750V - RUBBER SHEATHED CABLE)

APPLICATION:
H07RN-F flexible rubber cables are suitable for use in domestic appliances, such as kitchens, portable or mobile equipment, electrical tools, transofrmers, pumps, welders, grinders etc.
Also for use in drainage and water treatment, cold environment and severe industrial environments. H07RN-F cable may be rated 450/750V where the installation has been built in protection.



FEATURES:

• Maximum conductor operating temperature: +90°C
• Maximum conductor temperature during short circuit: +250°C
• Lowest ambient temperature for fixed installation: -40°C
• Lowest ambient temperature for mobile installation: -25°C
• UV, sunlight, water, oil, abrasion resistant
• Max continuous operating conductor temperature in normal use:
• +60°C ( in every case of mobile installation )
• +90°C ( fixed protected installation )

SIZE:

3C X 1.0MM	3C X 1.5MM	3C X 2.5MM	3C X 4MM
3C X 6MM	3C X 10MM	3C X 16MM	3C X 25MM
3C X 35MM	3C X 50MM	3C X 70MM	3C X 95MM
3C X 120MM	3C X 150MM
